| Tube | Anode Ag 50 kV et 200 µA, 6 to 50 kV |
| Detector | GOLDD (geometrically optimized wide area drift detector) |
| Analytical range | Up to 30 elements from Mg to U (varies by application) |
| Dimensions | 244 x 230 x 95,5 mm |
| Weight | 1,3 kg |
| Available measurement modes | Alloy, bulk, plastic, custom |
| Power | Lithium-ion battery packs |
| Data capacity | Mémoire système interne de 32 Mo/espace de stockage utilisateur interne de 128 Mo |
| Data storage | Internal >10,000 readings with spectra |
| Data transfert | USB, Bluetooth, and RS-232 serial communication |
| Display | Tilting, color, touch-screen display |
| Electric consumption | 0 à 200 µA |
| Camera | Integrated CCD camera for locating and storing images |
| Security | Password-protected user security |
| Software | NDT Niton Data Transfer |
| Standard accessories | Locking shielded carrying caser Shielded belt holster Two lithium-ion battery packs 110/220 VAC battery charger/AC adaptor PC connection cables (USB and RS-232) Niton Data Transfer (NDT) PC software Safety lanyard Check samples/standards |
| Optional accessories | 3 mm small-spot collimation Thermo Scientific SmartStand™ portable test stand, stationary (bench-top) test stand, mobile test stand, Field Mate™ Thermo Scientific Extend-a-Pole™ extension pole Soil testing guard |
| Compliance | CE, RoHS |
