Technical Specification

• Scan Accuracy: up to 0.05mm (Rapid Scan) up to 0.04mm (Laser Scan)
• Scan Speed: 20 frames/s
• Point Distance: 0.25-3mm (Rapid Scan) 0.05-3mm (Laser Scan)
• Maximum Scan Range: 420*440mm (Rapid Scan) 380*400mm (Laser Scan)
• Working Distance: 470mm
• Light Source: Blue LED (Rapid Scan) 7 Blue Laser Crosses (Laser Scan)
• Software: ExScan HX, Solid Edge Shining 3D Edition
• Output Formats: OBJ, STL, ASC, PLY, P3, 3MF
• Scanner Body Weight: 0.7kg
• Size of Scanner: 108mm x 110mm x 237mm
